What are the types of commonly used terminals?

Author: Bos Hardware EditorSource:www.bosiwj.comRelease time:2019-08-06-01:52点击率:6338

  With the rise of the electronics industry, more and more products are used for terminal blocks, and their applications are becoming more and more extensive. In fact, the terminal block is an accessory product used to realize electrical connection, which is divided into the category of connectors in the industry. Many people may not know the types of terminals very well, and do not know what type. Below, the editor of Dongguan Bos Hardware, a manufacturer of wiring terminals for more than 10 years, will help you to introduce several common terminals.

精密端子



What are the types of commonly used terminals?

1. Pluggable terminals

It consists of two parts plug-in connection, one part presses the wire, and then plugs into the other part, which is soldered to the PCB board. The mechanical principle of the bottom connection and the anti-vibration design ensure the long-term airtight connection of the product and the reliability of the finished product. Mounting ears can be added at both ends of the socket. The mounting ears can protect the tabs to a large extent and prevent the tabs from being arranged in a bad position. At the same time, this socket design can ensure that the socket can be correctly inserted into the mother body.


Sockets can also have assembly buckles and locking buckles. The assembly buckle can be used to more firmly fix to the PCB board, and the locking buckle can lock the mother body and the socket after the installation is completed. Various socket designs can be matched with different parent insertion methods, such as: horizontal, vertical or inclined to the printed circuit board, etc., and different methods can be selected according to customer requirements. You can choose either metric wire gauge or standard wire gauge, which is the most popular terminal type on the market.

插拔式接线端



2. Barrier terminal block

It can realize safe, reliable and effective connection, especially in the environment of high current and high voltage, it is widely used.

栅栏式接线端子



3. Spring terminal block

It is a new type of terminal using a spring device, which has been widely used in the world's electrical and electronic engineering industries: lighting, elevator control, instrumentation, power, chemistry and automotive power.

弹簧式接线端子



The above is what bosi introduced to you about the types of commonly used terminals: http://www.bosiwj.com/mp-16.html

I hope that the major customers can help everyone to distinguish when purchasing products. If you are interested, you may wish to learn about our products from Dongguan Bosi. We customize various specifications of terminal blocks. The materials are made of high-quality copper materials. We strictly control the quality of products and provide you with professional services and high-quality products.
